FTTA Fiber To The Antenna outdoor CPRI cable with LC connector
Application
1.Multi-purpose Outdoor.
2.For connection between distribution box and RRH.
3.Deployment in Remote Radio Head cell tower applications.
Features
1.Easily add/install jumper cables for a future expansion.
2.Low insertion loss and added loss.
3.Height of attenuation.
4.Flexibility with small bending radius and excellent cable routing
properties.
5.End-face geometry and quality superior than IEC and Telcordia
standards.
6.The material in the jumpel cable are all-weather and
UV-resistant.
7.Mechanical performance: IEC 61754-20 & IEC 61754-4 standard.
8.RoHS and REACH materials compliant.
Connector Types
| Type | Reference | Note |
LC | IEC 61754-20 | Single mode duplex | APC: Green connectors , Green boots UPC: Blue connectors , White boots |
| Multimode duplex | UPC: Grey Connectors , White boots |
SC | IEC 61754-4 | Single mode simplex | APC: Green connectors, Green boots UPC: Blue connectors, Blue boots |
| Multimode simplex | UPC: Grey Connectors, Grey boots |
| Jumper tolerance requirement |
| Overall length (L) (M) | length of tolerance(CM) |
| 0＜L≤20 | +10/-0 |
| 20＜L≤40 | +15/-0 |
| L＞40 | +0.5%L/-0 |
Mechanical Characteristics
| Test | Conditions | Reference |
| Endurance | 500 matings | IEC 61300-2-2 |
| Vibration | Frequency: 10 to 55Hz, Amplitude: 0.75mm | IEC 61300-2-1 |
| Cable retention | 400N (main cable); 50N (ranch part) | IEC 61300-2-4 |
| Strength of coupling mechanism | 80N for 2 to 3mm cable | IEC 61300-2-6 |
| Cable torsion | 15N for 2 to 3mm cable | IEC 61300-2-5 |
| Fall | 10 drops, 1m drop height | IEC 61300-2-12 |
| Static lateral load | 1N for 1h (main cable); 0.2N for 5min (ranch part) | IEC 61300-2-42 |
| Cold | -25°C, 96h duration | IEC 61300-2-17 |
| Dry heat | +70°C, 96h duration | IEC 61300-2-18 |
| Change of temperature | -25°C to +70°C, 12 cycles | IEC 61300-2-22 |
| Humidity | +40°C at 93%, 96h duration | IEC 61300-2-19 |
