    6 Ports AF PoE Network Switch 4 PoE 10/100M Ports 2 Uplink 100M

    Ask Lasest Price
    Brand Name : Optfocus
    Model Number : OFS-PE-DT6-I
    Certification : CE,RoSe
    Price : 8USD
    Payment Terms : T/T, Western Union
    Supply Ability : 3000 PCS PER MONTH
    Delivery Time : 5-12 working days
    • Product Details
    • Company Profile

    6 Ports AF PoE Network Switch 4 PoE 10/100M Ports 2 Uplink 100M

    OEM and ODM 10/100M reverse 6 Ethernet port POE NETWORK SWITCH

    Product Name6-Ports AF PoE Switch with 4 PoE 10/100M Ports and 2 Uplink 100M
    ModelOFS-PE-DT6-I
    Connector Type4x 10/100M copper cable RJ45 ports(4 PoE 10/100M ports+2 Uplink 100M)
    Network Media10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or more UTP (≤100 meter)
    Bandwidth1.2Gbps (non-blocking)
    Address Database Size1K
    Forwarding ModeStore-And-Forward
    Network Protocols

    IEEE 802.3i 10BASET; IEEE 802.3u 100BASETX; IEEE 802.3x Flow Control;

    IEEE 802.1af DTE Power via MDI; IEEE 802.3af

    LED DisplaySystem: power supply; Every Port: connecting, PoE working status
    Power SupplyPower input: AC100-240V 50/60Hz; (every country use a custom power plug)
    PoE PortsPort 1-8 support POE
    PoE Port Power15.4W for each POE port
    PoE StandardIEEE 802.3af
    Led indicator

    Green: Ethernet

    Red:PoE

    SW:

    On: VLAN, 100meters

    Flashing: VLAN, 250meters

    Off: VLAN Closed,100meters

    Flashing: VLAN Closed, 250meters

    Working Environment

    Operating Temperature: -20° ~ 55 ° C; Storage Temperature: -40 ° ~ 85 ° C;

    Operating Humidity: 10% ~ 95%, non-condensing

    CertificationCE Mark ,commercial; CE/LVD EN60950, RoHS
    RadiationCE mark, commercial; FCC Part 15 Class B; VCCI Class B; EN 55022 (CISPR 22), Class B
    Transmission DistanceData transmission distance: 100m, 250m( when on 10M data rate with Cat6.)
    Warranty2year warranty
