    FTTH Fiber-home Terminal GPON ONU 1GE+3FE with WIFI compatibilible for Fiberhome Huawei olt

    Ask Lasest Price
    Brand Name : OPTFOCUS
    Model Number : OFSE624-W
    Payment Terms : T/T
    Supply Ability : 5000 piece per one week
    Delivery Time : 5-7working days
    Certification : CE ISO
    Price : $12 usd - $16.5 usd
    • Product Details
    • Company Profile

    FTTH Fiber-home Terminal GPON ONU 1GE+3FE with WIFI compatibilible for Fiberhome Huawei olt

    FTTH Fiber-home Terminal GPON ONU 1GE+3FE with WIFI Compatible with Fiberhome Huawei Olt

    Product Description


    Most popular & high quality FTTH 1GE+3FE Ethernet ports with WiFi GPON ONU for office use


    Technical Specifications

    ItemParameter
    PON Interface1GPON interface, SC single-mode/single-fibre,uplink 1.25Gbps, downlink 2.5Gbps
    User Ethernet InterfaceRJ45Port connects to local internet,1 GE port and 3 FE port automatically,1*WIFI
    Power Interface12V DC Power supply ,An external 12V 0.5A AC/DC power supplyadapter
    Data Transmission ParameterPON Throughput: Downstream 950Mbps; Upstream 930Mbps
    Ethernet: 1 GE port and 3 FE
    Packet Loss Ratio: <1*10E-12
    latency: <1.5ms
    Network ManagementSupport IEEE802.3 QAM, ONU can be remotely managed by OLT
    Support Remote management through SNMP and Telnet
    Local management
    Management FunctionStatus monitor, Configuration management, Alarm management, Log management
    LED IndicatorPWR: Power up or down
    OPTIN: Optical Link Status
    LINK:ONU Registered
    ETH: Link Status of Ethernet Interface
    LAN:Link Status of Ethernet Interface
    WIFI: WIFI status
    PowerExternal 12V 1A AC/DC power supply adapter
    Power consumption: < 12W
    Physical SpecificationsItem Dimension:180mm(L) x 120mm(W) x27mm (H)
    Item weight:0.2kg
    Environmental SpecificationsOperating temperature: 0 to 50ºC Storage temperature: -40 to 85ºC Operating humidity: 10% to 90%(Non-condensing) Storage humidity: 5% to 95%(Non-condensing)

    Feature:

    • Support port-based rate limitation and bandwidth control;

    • In compliant with IEEE802.3ah Standard

    • Up to 20KM transmission Distance

    • Support data enscryption, group broadcasting, port Vlan separation ,RSTP,etc.

    • Support Dynamic Bandwidth Allocation (DBA)

    • Support ONU auto-discovery/Link detection/remote upgrade of software;

    • Support VLAN division and user separation to avoid broadcast storm;

    • Support power-off alarm function ,easy for link problem detection

    • Support broadcasting storm resistance function

    • Support port isolation between different ports

    • Support ACL and SNMP to configure data packet filter flexibly

    • Specialized design for system breakdown prevention to maintain stable system

    • Support software online upgrading

    • EMS network management based on SNMP ,convenient for maintenance

    Physical Pic Reference :


    Chassis Dimension:


    Package Dimension:

    Here is package box dimension of 1 port EPON ONU for your reference.

    size for 1 port EPON ONU: 185x110x40mm


    Power Supply Standard:


    Application
