| The product model | L3 48+6+4 10Gigabit Ethernet Switch |
| Basic characteristics |
| Fixed port | 48 1G optical ports, 6 1G electrical combo ports |
| Extensible port | 4 extensible 10G ports |
| Backplane bandwidth | 176Gbps |
| Packet forwarding rate | 130.944Mpps |
| Processor | RISC 400MHz |
| Flash memory capacity | 8MB |
| The memory capacity | 128MB |
| Address table | 32K |
| Product characteristics |
| Spanning tree | Support STP, RSTP, MSTP
Support PVST/PVST+ |
| VLAN | Support port-based VLAN
Support MAC-based VLAN
Support 802.1Q labeled VLAN
Support for Super Vlan
Support for Private Vlan
Support for the GVRP dynamic VLAN configuration
Support QinQ and flexible QinQ
Support for Voice VLAN |
| Flow control | Based on a standard IEEE 802.3x flow control
Using IEEE 802.1Qbb priority flow control
Support CAR function |
| Broadcast control | Restraining broadcast storm, stop sending so long as reaching a
critical point |
| multicast control | IGMP Snooping multicast message automatic monitoring |
| multicast routing | IGMP v1/v2/v3, MLDv2
PIM-SM, OLINK&PIM-DM
DVMRP (Distance Vector Multicast Routing Protocol)
GMRP (multicast dynamic registration protocol) |
| Port binding | Each group of a maximum of 8, while support 128 group
LACP dynamic or static polymerization |
| Port mirroring | Support based on flow classification mirroring and port mirroring |
| Stacked | Stacked 16 hard, soft stacking 32
Using clustering techniques, with a unified centralized management
of IP address to do address resource saving |
| Routing management | Static routing
RIP v1/v2, OSPFv2, BEIGRP (compatible with Cisco EIGRP), BGPv4,
ISIS, BGP
Anti virus intelligent routing function |
| Strategy routing | Support based on IP strategy routing |
| The proxy function | Support Proxy ARP, DNS Proxy |
| Redundancy backup | Support for VRRP, HSRP Hot Standby Router Protocol |
| Characteristics of DHCP | DHCP Server, DHCP Client and support DHCP relay |
| Function of NAT | Support the static or dynamic NAT address translation function |
| Safety characteristics | IEEE 802.1x port certification, PKI certification
Port Security (Port Security) function Hardware support for IP ACL ACL ACL, MAC, Vlan
Hardware support for port based user IP+MAC+Vlan ID+ user account a
variety of factors combined to bind
Support IP Source Guard
Support WEB interface user authentication
Remote RADIUS, TACACS+ certification User classification management and password protection Net shield technology
Safety control technology
Policy control list |
| Quality of service | IEEE 802.1Qau congestion mechanism
Each port 8 send queue mapping 802.1p 8 priority
WRED, WFQ, SP and FIFO queue scheduling algorithm
Best-Effort Service
Differentiated Service
Strict Priority
Weighted Round Robin
First come first served
TOS to mark
RTS |
| Network management | SNMP v1/v2/v3
RMON (1,2,3,9 group)
Telnet
WEB interface
Support for cluster management
Support SSH
Support for PDP (compatible with Cisco CDP.)
To support the fan, temperature, system log, hierarchical alarm |
| Physical characteristics |
| Appearance size | 442mm × 285mm × 44mm |
| Power characteristic | AC 110-240V adaptive, 47-63Hz, 1A/230V, RPS power hot backup |
| Power | 80W |
| Indicator lamp | Power indicator, indication of system, connecting / transceiver
instructions |
| Environment humidity / temperature | 0-50 ℃ operation,-40-70 ℃ preservation,0-90% no condensation |
